TEMPO SIDEKICK T&N 1137-5002 50605263/783310605263
Available*
Item # 23655000
Model # 783310605263
$1,906.25
financing available. Learn More
* Notes on Availability:
If item is in stock, it will ship same day.
Lead times vary, contact us for more info.
(Images may not be of the actual item being sold.)
- Product Description
- You Might Also like
- Recently Viewed
Generic
Class
Group
Type
Manufacturer
LOT
Meters
Test Equipment
Subscriber Loop Tester
Multimeters-VOM-Brownie
Tempo Communications, Inc.
Warning: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.govProduct Description
GREENLEE SIDEKICK T&N 1137-5002 50605263/783310605263 NEW FEATURES
Determines stressed noise susceptibility of dry and working pairs. Measures resistance, AC/DC volts, and capacitive kick. Provides tone for twisted pair or crossed conductor identification. Single setup for testing Tip-Ring, Tip-Ground, and Ring-Ground. Minimal drying effect in all ranges. Field replaceable leads. Soft case with adjustable strand hook. Low Battery indicator light. Five Transmission and Noise Tests
BENEFITS Increased testing capabilities. Reduces repeat service calls. Eliminates service interruptions. Works on any twisted pair application. Increases technician productivity. Reduces training time. Provides quick return on investment. Reduces the number of test sets required
The new Sidekick T&N combines the functions of the Sidekick 7B plus the features of Transmission and Noise testing. The result is an even more versatile test set that identifies frequently missed faults as well as tests and qualifies the transmission quality of POTS lines. The additional features include:
Loop Current testing Circuit Loss testing Metallic Noise testing Power Influence testing Load Coil detection The familiarity of the Sidekick's analog meter and rugged, lightweight design, combined with five new test functions, provide quality loop testing for POTS lines.
SPECIFICATIONS Dimensions (LxWxH) 10.75 x 4.25 x 2.5 inches Weight (batteries, test leads, wand and receiver) 2 lbs. Resistance Rx1: Reads 0 to 2000 ohms Rx1,000: Reads 0 to 2 megohms Rx10,000: Reads 0 to 20 megohms DC Voltage 0 to 100 Volts DC AC Voltage 0 to 200 Vrms Circuit Noise 0 to 90 dBrn Circuit Loss -15 to +1 dB Power Influence 50 to 100 dBrnC Load Coil Detector Up to 3 or 4 load coils Loop Current 0 to 100 mA Stress Test 0 to 90 dBrn Operating Temperature -20C to +60C Power Four AA batteries Part Number 1137-5000
Determines stressed noise susceptibility of dry and working pairs. Measures resistance, AC/DC volts, and capacitive kick. Provides tone for twisted pair or crossed conductor identification. Single setup for testing Tip-Ring, Tip-Ground, and Ring-Ground. Minimal drying effect in all ranges. Field replaceable leads. Soft case with adjustable strand hook. Low Battery indicator light. Five Transmission and Noise Tests
BENEFITS Increased testing capabilities. Reduces repeat service calls. Eliminates service interruptions. Works on any twisted pair application. Increases technician productivity. Reduces training time. Provides quick return on investment. Reduces the number of test sets required
The new Sidekick T&N combines the functions of the Sidekick 7B plus the features of Transmission and Noise testing. The result is an even more versatile test set that identifies frequently missed faults as well as tests and qualifies the transmission quality of POTS lines. The additional features include:
Loop Current testing Circuit Loss testing Metallic Noise testing Power Influence testing Load Coil detection The familiarity of the Sidekick's analog meter and rugged, lightweight design, combined with five new test functions, provide quality loop testing for POTS lines.
SPECIFICATIONS Dimensions (LxWxH) 10.75 x 4.25 x 2.5 inches Weight (batteries, test leads, wand and receiver) 2 lbs. Resistance Rx1: Reads 0 to 2000 ohms Rx1,000: Reads 0 to 2 megohms Rx10,000: Reads 0 to 20 megohms DC Voltage 0 to 100 Volts DC AC Voltage 0 to 200 Vrms Circuit Noise 0 to 90 dBrn Circuit Loss -15 to +1 dB Power Influence 50 to 100 dBrnC Load Coil Detector Up to 3 or 4 load coils Loop Current 0 to 100 mA Stress Test 0 to 90 dBrn Operating Temperature -20C to +60C Power Four AA batteries Part Number 1137-5000
