Multilink 066-214-10 Singlemode SC/APC Connector Blue Housing 3mm Boot Surelight Field Installabl
Available*
Item # 51296310
Model # 066-214-10
$8.10
financing available. Learn More
* Notes on Availability:
If item is in stock, it will ship same day.
Lead times vary, contact us for more info.
(Images may not be of the actual item being sold.)
- Product Description
- You Might Also like
- Recently Viewed
Generic
Class
Group
Type
Manufacturer
LOT
Connector
Fiber Optic Products
Fusion and Mechanical Splicing
Fiber Mechanical- Glue On Connector
Multilink
Warning: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.govProduct Description
Multilink 066-214-10 Singlemode SC/APC Connector Blue Housing 3mm Boot Surelight Field Installable
Multilink 066-214-10 Singlemode SC/APC Connector Blue Housing 3mm Boot Surelight Field Installable
Surelight® Field Installable Connector - SC/APC, Singlemode, 3mm 066-214-10 SC/APC, Singlemode, 3mm
General Specifications Nominal Fiber OD 125um Intermateibility TIA/EIA 604-3 Installation Time 3-5 Minutes Reusable/Times Yes/5 Durability < .3 dB, 500 Rating Technology Epoxy Free No Polish Tension < .2 dB, Change 3kg
General Specifications Product Type Field Installable Connector
Fiber Specifications Cable Compatibility 3mm Fiber Category Singlemode (OS1) Insertion Loss Typical 0.3 dB Reflectance, Typical #1 < -55 dB
Connector Specifications Connector Type SC/APC Polish APC Boot Color Gray Housing Color Green Housing Material Composite Ferrule Material Zirconia
Environmental Specifications Operating Temperature -40°C to +75°C
Safety Standard Specifications Standards EIA/TIA 568-B.3
Multilink 066-214-10 Singlemode SC/APC Connector Blue Housing 3mm Boot Surelight Field Installable
Surelight® Field Installable Connector - SC/APC, Singlemode, 3mm 066-214-10 SC/APC, Singlemode, 3mm
General Specifications Nominal Fiber OD 125um Intermateibility TIA/EIA 604-3 Installation Time 3-5 Minutes Reusable/Times Yes/5 Durability < .3 dB, 500 Rating Technology Epoxy Free No Polish Tension < .2 dB, Change 3kg
General Specifications Product Type Field Installable Connector
Fiber Specifications Cable Compatibility 3mm Fiber Category Singlemode (OS1) Insertion Loss Typical 0.3 dB Reflectance, Typical #1 < -55 dB
Connector Specifications Connector Type SC/APC Polish APC Boot Color Gray Housing Color Green Housing Material Composite Ferrule Material Zirconia
Environmental Specifications Operating Temperature -40°C to +75°C
Safety Standard Specifications Standards EIA/TIA 568-B.3
