WAVETEK SDA5000 SIGNAL LEVEL METER REPAIRED
Available*
Item # 23805490
Model # SDA5000
$1,916.25
financing available. Learn More
* Notes on Availability:
If item is in stock, it will ship same day.
Lead times vary, contact us for more info.
(Images may not be of the actual item being sold.)
- Product Description
- You Might Also like
- Recently Viewed
Generic
Class
Group
Type
Manufacturer
LOT
Catv
Test Equipment
Cable TV
Testers-Monitors
Wavetek
Warning: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.govProduct Description
WAVETEK SDA5000 SIGNAL LEVEL METER REPAIRED Wavetek SDA-5000 Digital Analyzer and Sweep System
The Stealth Digital Analyzer (Wavetek SDA-5000) product family offers a true "One Box" solution for HFC network testing and deployment of digital video, data, and traditional analog services. While preserving the rugged design and industry standard RF sweep technique of its Stealth Sweep System predecessor, the SDA series now adds test features to qualify the network for todays high growth subscriber services. "Find and Fix" tools are included that reduce technician time for the most labor intensive maintenance and troubleshooting assignments, like tracking down reverse ingress, optical node alignment, proof-of-performance testing, and return path alignment.
For these demands, the SDA provides advanced QAM analysis (optional), a powerful 5 to 1,000 MHz spectrum display with cable modem analysis (Zero Span), PathTrak Field View, and full forward and reverse sweep capability. And with the versatile combination of standard and optional features, the SDA can be customized for both the cable operators network technology level and budget.
Features
¦Forward and reverse sweep ¦Cable modem analysis using zero span mode ¦Full in-service proof-of-performance analyzer ¦Equalizer Stress and Microreflections ¦QAM view: BER, MER and Constellation ¦Find ingress fast with Field View option Specifications
Frequency 5 - 1000 MHz Level Measurement -40 to +60 dBmV Carrier-To-Noise =52 dB HUM Measurement 0 - 10% Depth of Modulation 80 - 100% Tilt Measurement, Hi-Lo ? Resolution 0.1 dB Sweep Frequency Range 5 - 1000 MHz Spectrum Mode Spans 3, 5, 10, 20, 50 MHz Zero-Span Mode 100 Hz - 99 MHz Intermodulation Distortion =60 dB Forward/Reverse Transmitter & Telemetry Frequency Range 5 - 1000 MHz
For these demands, the SDA provides advanced QAM analysis (optional), a powerful 5 to 1,000 MHz spectrum display with cable modem analysis (Zero Span), PathTrak Field View, and full forward and reverse sweep capability. And with the versatile combination of standard and optional features, the SDA can be customized for both the cable operators network technology level and budget.
Features
¦Forward and reverse sweep ¦Cable modem analysis using zero span mode ¦Full in-service proof-of-performance analyzer ¦Equalizer Stress and Microreflections ¦QAM view: BER, MER and Constellation ¦Find ingress fast with Field View option Specifications
Frequency 5 - 1000 MHz Level Measurement -40 to +60 dBmV Carrier-To-Noise =52 dB HUM Measurement 0 - 10% Depth of Modulation 80 - 100% Tilt Measurement, Hi-Lo ? Resolution 0.1 dB Sweep Frequency Range 5 - 1000 MHz Spectrum Mode Spans 3, 5, 10, 20, 50 MHz Zero-Span Mode 100 Hz - 99 MHz Intermodulation Distortion =60 dB Forward/Reverse Transmitter & Telemetry Frequency Range 5 - 1000 MHz
