CORNING/SIECOR 95-200-51 ST, SM UNICAM CONNECTOR **DISCONTINUED**

SIECOR 95-200-51 ST, SM UNICAM CONNECTOR NEW 95-200-51 ST Compatible Single-mode UniCam Connector with Super PC Polish and rotating cam

Corning Cable Systems has improved the actuation method of the Universal CamLite ® (UniCam ® ) connector for the ST ® compatible and the FC, and they are now terminated by a rotating cam action. One tool fits all! This feature makes the connector easier to use, provides improved yield, and allows for less expense and universal tooling. The UniCam connector requires no polishing and no epoxy during installation, with no compromise in performance. Corning Cable Systems’ UniCam connector is the only field-installable single-mode connector that can guarantee reflectance performance in the field. The Super PC is =-40 dB and the Ultra PC is =-55 dB, every time. The UniCam connector solves all the slack storage problems created with interconnection systems. Interconnection jumpers no longer have to be pre-engineered to length. Simply buy a pigtail, cut it to length, and install a UniCam connector on the end. Likewise, the UniCam connector is the ultimate solution for retrofitting and upgrading systems to better connector technology for the future. The existing connector may be cut off at the boot, and a UniCam connec-tor installed without disturbing the existing cable plant. The UniCam connector can best be described as a mini pigtail. It incorporates a specially selected single-mode fiber stub that is fully bonded into the ferrule. The other end is precisely cleaved and placed into the patented alignment mechanism of our mechanical splice. Installation requires that the field fiber be cleaved, cleaned, and inserted inside the mechanical splice section. A small installation tool completes the connector in less than one minute on MIC ® cables. Installation on jacketed cables requires merely three minutes. Tooling has been improved and is now universal for ST compatible, SC, and FC, both single-mode and multimode. The connector and fiber are now held stationary on a hori-zontal plane. No movement of connector or fiber during installation is a substantial improvement over the CamLite installation procedure. As systems are upgraded, and as fiber moves outward from the central office, and fiber slack storage becomes a bigger problem, the UniCam connector is the answer. It provides a graceful solution for all applications. In addition, one can move to Ultra PC performance without changing installation procedures. Simply order a UniCam connector with an Ultra PC finish. The improved Universal CamLite (UniCam) connector is the ideal solution for all of your requirements for field-installable fiber optic connectors. UniCam ® Connector Family – SC, FC, and ST ® Compatible Fiber Stub Mechanical Splice with Index Matching Gel Field Fiber Factory Polished Features/Benefits Installs in less than one minute Redesigned ST compatible and FC designs with rotating cam Universal tool terminates all three styles – ST compatible, SC, and FC Guaranteed reflectance performance of =-40 dB for Super PC Ultra PC performance with guaranteed reflectance performance of =-55 dB Eliminates cable slack storage Available in single-mode and multimode ST compatible, FC, and SC connectors No epoxy, no polishing No consumables Minimal tool kit and training required Proven performance
