SIECOR 012K62-A7024-24 12-F MM PLENUM FANOUT
Available*
Item # 51211050
Model # 012K62-A7024-2
$2.25
financing available. Learn More
* Notes on Availability:
If item is in stock, it will ship same day.
Lead times vary, contact us for more info.
(Images may not be of the actual item being sold.)
- Product Description
- You Might Also like
- Recently Viewed
Generic
Class
Group
Type
Manufacturer
LOT
Cable
Wire and Cable
Fiber Optic
MIC Type of Cable
Corning Inc
Warning: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.govProduct Description
SIECOR 012K62-A7024-24 12-F MM PLENUM FANOUT NEW 12 fiber multi mode 62.5/125 plenum break out cable in 2000 meter reels.
Features / Benefits 12 fiber, 900 µm buffered fiber, Small diameter and bend radius allow easy installation in space-constrained areas. Available in 62.5 µm multimode, Color-coded fibers in accordance with EIA/TIA 598 for easy identification, Listed UL-910 and FT-6 Performance Applications Intrabuilding backbone and horizontal installations in plenum, general purpose environments flexible OFNP MIC Cable Outer Jacket Dielectric Strength Members Ripcord Tight Buffered Fiber. TBII buffered fiber.
Transmission Performance 62.5/125µm (850/1300 nm) Maximum Attenuation (dB/km) 3.75/1.5 Typical Attenuation @ 23°C (dB/km) 3.0/1.0 Minimum LED Bandwidth (MHz·km) 200/500
Per Siecor/Corning - Rosemary - the size of buffer around the fiber strand is 250mm.
Transmission Performance 62.5/125µm (850/1300 nm) Maximum Attenuation (dB/km) 3.75/1.5 Typical Attenuation @ 23°C (dB/km) 3.0/1.0 Minimum LED Bandwidth (MHz·km) 200/500
Per Siecor/Corning - Rosemary - the size of buffer around the fiber strand is 250mm.
