Product Description
Multilink 649-065-12Mrwh15-W Hinged Cover Molding White Fittings For Mrm & Mrc Series Molding
Multilink 649-065-12Mrwh15-W
Hinged Cover Molding White Fittings For Mrm & Mrc Series Molding
Hinged Overlay Molding - White, 8Ft
649-065-12
Hinged Overlay, White, 8Ft.
General Specifications
Application Indoor
Impact Resistance 2.5Ft. Lbs. Referencing Tr1334 Section 5.4
Chemical Resistance Retains A Minimum Of 50% Of Tensile Strength After 30 Day Exposure To 3% H2So4, .2N Naoh, Nh3, 90% Alcohol, Kerosene, 10% Lgepal
Uv Resistance Astm 155 1000 Hour Exposure Per Gr3126Requirement
Fungus Resistance Astm G21 Zero Rating Per Gr 3126 Requirement
Uom 80 Ft. / Carton
Crush Resistance 300 Lbs. Per Gr3126 Requirement
General Specifications
Installation Temperature Range -18�C To 45�C (0�F To 113�F)
Physical Specifications
Dimensions 2.58" X 4.86" X 8'
Color White
Material Rigid Flexible Pvc
Environmental Specifications
Operating Temperature -18�C To 58�C (0�F To 136�F)
Safety Standard Specifications
Safety Standard Ul 2024:2014 Ed. 5 And Csa C22.2 #262:2004 Ed. 1 Optical Fiber Cable And Communication Cable Raceway Systems (Select Colors)Read More
