JONARD DFB2426 24-26AWG BIT/SLEEVE WRAP/UNWRAP NEW
This patented wire 24-26 AWG wrapping/unwrapping bit and sleeve set offers a revolutionary way to approach wire wrapping by combining both wire wrapping and unwrapping functions into one bit/sleeve set. This bit and sleeve set features the following:
Precision machined for high-quality wire wrapping in the clockwise direction and unwrapping in the counterclockwise direction Easily switch between wrap and unwrap mode by retracting or extending the sleeve and flipping the switch on a PTX Wire Wrapping/Unwrapping Tool Maximizes the efficiency of wire wrapping and unwrapping 24-26 AWG wires, while eliminating the need to purchase or carry other extra tools for unwrapping Retractable wire wrapping sleeve is coated with a durable 1000V dielectric material to prevent pin-to-pin shorting The kit includes:
KB-DF2426 Wrap/Unwrap Bit (24-26 AWG) P-DF2426 Replacement Sleeve Assembly (DFB2426, 24-26 AWG)
Specifications Wrap Function Wrap, Unwrap
Wire Gauge 24-26 AWG (0.50-0.40 mm)
Minimum Terminal Diagonal 0.054" (1.37 mm)
Maximum Terminal Diagonal 0.073" (1.85 mm)
Terminal Hole Depth 0.50" (12.70 mm)
Terminal Hole Diameter 0.075" (1.90 mm)
Effective Radius 0.098" (2.48 mm)
Wrap Post Size 0.045" (1.14 mm)
Length 5" (127mm)
Weight 0.133 lbs (60.33g)
UPC No. 811490013919
This patented wire 24-26 AWG wrapping/unwrapping bit and sleeve set offers a revolutionary way to approach wire wrapping by combining both wire wrapping and unwrapping functions into one bit/sleeve set. This bit and sleeve set features the following:
Precision machined for high-quality wire wrapping in the clockwise direction and unwrapping in the counterclockwise direction Easily switch between wrap and unwrap mode by retracting or extending the sleeve and flipping the switch on a PTX Wire Wrapping/Unwrapping Tool Maximizes the efficiency of wire wrapping and unwrapping 24-26 AWG wires, while eliminating the need to purchase or carry other extra tools for unwrapping Retractable wire wrapping sleeve is coated with a durable 1000V dielectric material to prevent pin-to-pin shorting The kit includes:
KB-DF2426 Wrap/Unwrap Bit (24-26 AWG) P-DF2426 Replacement Sleeve Assembly (DFB2426, 24-26 AWG)
