PLP 288811353T DROP CBL DEAD-END ADSS WITH THIMBLE.371-.380 *ORDER MINIMUM* 100
Available*
Item # 30182090
Model # 288811353T
$6.87
financing available. Learn More
* Notes on Availability:
If item is in stock, it will ship same day.
Lead times vary, contact us for more info.
(Images may not be of the actual item being sold.)
- Product Description
- You Might Also like
- Recently Viewed
Generic
Class
Group
Type
Manufacturer
LOT
Deadend
Material and Supplies
Hardware- Screws- Bolts
Clamps
Preformed Line Products
Warning: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.govProduct Description
Preformed Line Products 288811353T FIBERLIGN® ADSS DROP CABLE DEAD-ENDS = ROUND PROFILE Cable Diameter Range 0.371-0.380 in., Yellow. Overall length 27 in. *Add suffix code “T” to Dead-end catalog number to receive P/N 00065474 Thimble. P/N 00065474 is a ˝" standard thimble - weight is 0.12 lbs. each.
Adapts to all ADSS Drop Designs: -Round Profile -Flat Profile Span Lengths up to 300’ (91.4 m) -Drop Applications (Structure to Premise)
Easy Installation: No Tools Required Connect to Conventional Fittings -Direct Connection to 1.5" (38.1 mm) diameter fitting -Thimble used at J-hooks
Tested: Elevated temperature at 140o F (60o C) tensile test -Installation Load typically 100 lbs (45.36 kg) Room temperature tensile test -Maximum Rated cable load 250 to 500 lbs (113.4 kg to 226.8 kg)
Add suffix code "T" to receive P/N 00065474 Thimble
Adapts to all ADSS Drop Designs: -Round Profile -Flat Profile Span Lengths up to 300’ (91.4 m) -Drop Applications (Structure to Premise)
Easy Installation: No Tools Required Connect to Conventional Fittings -Direct Connection to 1.5" (38.1 mm) diameter fitting -Thimble used at J-hooks
Tested: Elevated temperature at 140o F (60o C) tensile test -Installation Load typically 100 lbs (45.36 kg) Room temperature tensile test -Maximum Rated cable load 250 to 500 lbs (113.4 kg to 226.8 kg)
Add suffix code "T" to receive P/N 00065474 Thimble
